microATX - Ryzen 7 5800X / 3.8 GHz - RAM 16 GB - SSD 1 TB - NVMe, HDD 1 TB - GF RTX 3070 - GigE - WLAN: Bluetooth 2.1, 802.11a/b/g/n/ac - Win 10 Home 64-bit - monitor: none
| Main Specifications | |
|---|---|
| Product Description | ZOTAC MEK HERO G1 A5837 - microATX - Ryzen 7 5800X 3.8 GHz - 16 GB - SSD 1 TB, HDD 1 TB |
| Type | Personal computer - microATX |
| Processor | AMD Ryzen 7 5800X / 3.8 GHz (4.7 GHz) (8-core) |
| RAM | 16 GB (installed) / 128 GB (max) - DDR4 SDRAM |
| Storage Controller | SATA |
| Hard Drive | SSD 1 TB - PCI Express - M.2 - NVM Express (NVMe) |
| Hard Drive (2nd) | HDD 1 TB - SATA |
| Optical Storage | No optical drive |
| Graphics Controller | NVIDIA GeForce RTX 3070 |
| Video Memory | 8 GB GDDR6 SDRAM |
| Audio Output | 7.1 channel surround |
| Networking | GigE, 802.11a, 802.11b/g/n, Bluetooth 2.1, 802.11ac |
| OS Provided | Windows 10 Home 64-bit Edition |
| Dimensions (WxDxH) | 8.7 in x 17.4 in x 16.2 in |
| Manufacturer Warranty | Limited warranty - labor - 3 years ¦ Limited warranty - parts - 1 year |
| General | |
| Type | Personal computer |
| Product Form Factor | microATX |
| Built-in Devices | Liquid cooling system with 240 mm radiator |
| Expansion / Connectivity | |
| Interfaces | 1 x headphones (1 top) ¦ 2 x microphone (1 top, 1 rear) ¦ 4 x USB 3.2 ¦ 1 x USB 3.0 ¦ 4 x USB 2.0 ¦ 2 x HDMI ¦ 1 x LAN (Gigabit Ethernet) ¦ 4 x DisplayPort ¦ 1 x audio line-out ¦ 1 x audio line-in ¦ 1 x PS/2 keyboard / mouse ¦ 1 x VGA |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - labor - 3 years ¦ Limited warranty - parts - 1 year |
| Miscellaneous | |
| Included Accessories | 2 x wireless antennas |
| RAM | |
| Installed Size | 16 GB / 128 GB (max) |
| Technology | DDR4 SDRAM |
| Effective Memory Speed | 3200 MHz |
| Rated Memory Speed | 3200 MHz |
| Networking | |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, Bluetooth 2.1, IEEE 802.11ac |
| Power | |
| Device Type | Power supply |
| Power Provided | 700 Watt |
| 80 PLUS Certification | 80 PLUS Gold |
| Storage Controller | |
| Type | 1 x SATA |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | NVIDIA GeForce RTX 3070 |
| Video Memory | 8 GB GDDR6 SDRAM |
| Video Interfaces | HDMI, DisplayPort |
| Max Monitors Supported | 4 |
| Audio Output | |
| Sound Output Mode | 7.1 channel surround |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | Windows 10 Home 64-bit Edition |
| Hard Drive | |
| Type | SSD - M.2 |
| Capacity | 1 x 1 TB |
| Interface Type | PCI Express |
| Features | NVM Express (NVMe) |
| Dimensions & Weight | |
| Width | 8.7 in |
| Depth | 17.4 in |
| Height | 16.2 in |
| Hard Drive (2nd) | |
| Type | HDD |
| Interface Class | Serial ATA |
| Capacity | 1 x 1 TB |
| Processor / Chipset | |
| CPU | AMD Ryzen 7 5800X |
| Clock Speed | 3.8 GHz |
| Max Turbo Speed | 4.7 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
