43" Diagonal Class IL01 Series LED-backlit LCD display - digital signage - with touchscreen (multi touch) - 4K UHD (2160p) 3840 x 2160 - Direct LED
| Main Specifications | |
|---|---|
| Product Description | BenQ IL4301 IL01 Series - 43" LED-backlit LCD display - 4K - for digital signage |
| Product Type | LED-backlit LCD flat panel display with touchscreen (multi touch) |
| Diagonal Class | 43" |
| Commercial Use | Yes - digital signage |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Frame Rate & Enhancement Technology | 60 Hz Frame Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| PC Interface | VGA (HD-15), DisplayPort |
| Technology | ADS |
| LCD Backlight Technology | Direct LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Commercial Features | Real-Time Clock (RTC), OPS Slot |
| Picture Enhancements | 72% Color Gamut NTSC |
| Speaker System | 2 speakers |
| Storage Capacity | 32 GB |
| USB | 2 ports |
| Included Accessories | Remote control, X-Sign Software |
| Voltage | AC 100-240 V (50/60 Hz) |
| Energy Class | Class G |
| Power Consumption Operational | 82 Watt |
| Power Consumption Stand by | 0.5 Watt |
| Dimensions (WxDxH) | 39.8 in x 3.8 in x 23.6 in |
| Weight | 41.45 lbs |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Energy Class | Class G |
| Power Consumption Operational | 82 Watt |
| Power Consumption SDR (On mode) | 82 kWh/1000h |
| Diagonal Class | 43" |
| Commercial Use | Yes - digital signage |
| Combined With | Touchscreen (multi touch) |
| Series | IL01 Series |
| Operating System | Android OS 8.0 |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| PC Interface | VGA (HD-15), DisplayPort |
| Modes | Portrait mode, landscape mode |
| Picture Enhancements | 72% Color Gamut NTSC |
| Design | 16.6mm bezel |
| Protection | Germ-resistant |
| Width | 39.8 in |
| Depth | 3.8 in |
| Height | 23.6 in |
| Weight | 41.45 lbs |
| Miscellaneous | |
| Included Accessories | X-Sign Software |
| Cables Included | VGA cable - 5 ft ¦ HDMI cable - 5 ft ¦ DisplayPort cable - 5 ft ¦ Touch cable - 5 ft |
| Compliant Standards | CEC, TUV Rheinland, DisplayPort 1.2, HDCP |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 85% RH (non-condensing) |
| Display | |
| LCD Display Technology | ADS |
| Pixel Pitch | 0.245 mm |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Frame Rate |
| LCD Backlight Technology | Direct LED |
| Coating | Anti-glare, 9H hardness |
| Image Contrast Ratio | 1200:1 |
| Brightness | 400 cd/m² |
| Touchpoints Qty | 40 |
| Response Time | 8 ms |
| Backlight Life | 40,000 hour(s) |
| Commercial Features | Real-Time Clock (RTC), OPS Slot |
| Additional Features | Infrared touch technology, 10-bit support, Over-the-Air Update (OTA), Device Management Solution (DMS) |
| Connections | |
| Connector Type | Infrared input ¦ HDMI output ¦ SPDIF output ¦ Touch ¦ 2 x USB 2.0 ¦ DisplayPort ¦ 2 x HDMI input ¦ VGA input ¦ Audio line-in ¦ Audio line-out ¦ RS-232 ¦ 2 x LAN |
| Remote Control | |
| Type | Remote control |
| Audio System | |
| Speaker System | 2 speakers |
| Output Power / Total | 20 Watt |
| Speakers | 2 x main channel speaker - 10 Watt |
| Dimensions & Weight (Shipping) | |
| Weight (Shipping) | 52.91 lbs |
| Stands & Mounts | |
| Flat Panel Mount Interface | 200 x 400 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 2 |
| Configuration | ARM Cortex-A73 Dual-Core + ARM Cortex-A53 Dual-Core - 3 GB - 32 GB - Mali-G51 MP2 |
