8 x audio line-in / microphone (XLR) - top ¦ 8 x audio line-in (phone 6.3 mm) - top ¦ 8 x channel insert (phone 6.3 mm) - top ¦ 2 x mix insert (phone 6.3 mm) - top ¦ 1 x mix output (XLR x 2) - top ¦ 1 x monitor output (phone 6.3 mm x 2) - top ¦ 2 x audio line-out (mono) (phone 6.3 mm) - top ¦ 2 x audio line-in (stereo) (phone 6.3 mm x 2) - top ¦ 1 x track input (mini-phone stereo 3.5 mm / RCA x 2) ¦ 1 x recording output (mini-phone stereo 3.5 mm / RCA x 2) ¦ 1 x headphone output (phone 6.3 mm) - top
Dimensions & Weight
Width
13 in
Depth
14.3 in
Height
3.6 in
Weight
10.14 lbs
Mixer
Rack Mount
Rack-mountable
Channels Qty (total)
16-channel
Frequency Response
20 Hz - 20 kHz
Control Types
Knobs, faders
Headphones Output
Yes
Channel Description
Mic Channels
8 mono
Mic Channels Connector
XLR
Line Channels
8 mono
Line Channels Connector
Phone stereo 6.3 mm
Mic Preamplifier Gain Level
60 dB
EQ Band Qty
3
Fader Size
60 mm
Master Bus Fader Size
60 mm
